SC362 Stump Cutter

Stump Cutter

Width: 88.9 cm (minimum transport)
Weight: 598.7 kg
Fuel Type: Petrol
Power: 35 hp (26.1 kW)
Capacity: 17″ cutter wheel

Request a Quote

Find Nearest Branch Download Brochure

Features

With a 35 hp Vanguard engine, a hydraulic ground drive and a belt driven cutter head, the SC362 provides operators with ample power and manoeuvrability.

Key Features

35 hp (26.1 kW) Vanguard gasoline engine offers low vibration, low emissions and a limited three-year warranty.
Move easily between stumps with the selectable two-speed ground drive.
Vermeer AutoSweep® system (optional) monitors engine rpm and adjusts cutter wheel sweep rate.
All of the belts are found on one side of the machine for convenient belt servicing.

General Dimensions and Weights

Length: 110 inches / 279.4 cm
Height: 53 inches / 134.6 cm
Width (Without Duals): 35 inches / 88.9 cm
Width (With Duals): 49.8 inches / 126.5 cm
Height: 53 inches / 134.6 cm
Weight: 1320 lbs / 598.7 kg

Engine

Make and Model: Briggs & Stratton Vanguard
Horsepower: 35 hp / 26.1 kw
Torque (Max.): 53 ft-lb / 71.9 Nm
Fuel Tank Capacity: 6 gal / 22.7 L
Fuel Consumption (Max.): 3.2 gph / 12.1 lph
Fuel Type: Petrol
Air Cleaner: Dry-type safety element and restriction indicator
Oil Filter: Spin-on
Recommended Oil: 10W30 (See engine manual)
Oil Volume with Filter: 2 qt / 1.9 L
Cooling Medium: Air
Alternator: 20 amp
Clutch Type: Electric clutch with brake

Cutterwheel System

Cutterwheel Diameter (Without Teeth): 17 inches / 43.2 cm
Cutterwheel Thickness: 0.5 inch / 1.3 cm
Cutterwheel Speed: 1400 rpm
Cutterwheel Straight Line Dimension: 47 inches / 119.4 cm
Cutterwheel Cut Above Ground: 24 inches / 61 cm
Cutterwheel Cut Below Ground: 15 inches / 38.1 cm
Tooth Description: Yellow Jacket™ Cutter System
Number of Teeth: 16
Number of Indexes: 2
Number of Pockets: 16
Reversible Pockets: 16
Cutterwheel Guard: Standard
Chip Containment: 7.7 cu ft / 0.2 cu m

Cutterwheel Drive Components

Belt Type: V-Belt
Number of Primary Belts: 2 individual (matched pair)
Jackshaft Dimension: 1.3
Jackshaft Bearing Type: Sealed ball
Bearing Dimensions: 1.3 bore
Number of Secondary Belts: 6 Banded
Cutterwheel Shaft: 1.8 inches (4.8 cm)
Bearing Dimensions – Secondary Belt: 1.8 inches (4.8 cm) double spherical roller pillow block

Hydraulic System

Tank capacity: 4 gal / 15.1 L
Recommended Oil Type: Vermeer HyPower 68
System Type: Open-loop series system
Filtration Method: Pump suction strainer (100 mesh) and 6 micron return filter
Pump Flow at Maximum RPM: 3.7 gpm / 14 L/min
System relief pressure: 2030 psi / 140 bar
Flow Control: AutoSweep® (option) or 2 speed ground drive
Directional Control: Manual hydraulic value

Electrical System

System Voltage: 12 V
Battery: 400 CCA
Standard Gauges: Hourmeter
Warning Lights: Operator presence status, clutch engage/disengagement status
Switches: Two-speed ground drive, clutch engage/disengage, operator presence handles
Controller: Vermeer ACS
Shutdown System: Engine low oil pressure
